| Property | Test method | Conditions | Value |
| Physical and Mechanical | |||
| Cont. service temp. | 13000 h | 120°C | |
| Density | ISO 1183 | 1.31 | |
| Elongation at break | IEC 60811-1-1 | 250 mm/min | >350% |
| Hardness shore | ISO 868 | D | 69 |
| Radiation resistance | IEC 60544 | 4*10^5 Gy | |
| Temperature range | -40°C TO 120°C | ||
| Tensile strength at break | IEC 60811-1-1 | 250 mm/min | >25 MPa |
| Water absorption | DIN EN ISO 62 | 0.30% | |
| Electrical |
|||
| Dielectric constant | IEC 60250 | 50Hz/1MHz | 4.2/3.8 |
| Dissipation factor | IEC 60250 | 50Hz/1MHz | 0.022/0.033 |
| Volume resistivity | IEC 60093 | 10^16 ohm·cm | |
| Flammability | |||
| Combustion corrosivity | IEC 60754-2 | pH 7.7/ 16.9 uS/mm |
|
| Flame retardancy | IEC 60332-1 | 0.75mm² to 2.5mm² | pass |
| conductor |
|||
| Flame retardancy | UL 94 | 0.8 & 1.6 mm | V-2 |
| Oxygen index | ASTM D2863 | >31 % |
|
| Chemical | |||
| Acids | good |
||
| Bases | good |
||
| Fuels | excellent | ||
| Oils | excellent |
IMPORTANT
Habia Cable has compiled the information contained herein from what it believes are authoritative sources and believes that is accurate and factual as of the date printed.
It is offered solely as a convenience to its customers and is intended only as a guide concerning the materials mentioned.
Any changes in the data sheet will be made without notification.
Habia Cable has compiled the information contained herein from what it believes are authoritative sources and believes that is accurate and factual as of the date printed.
It is offered solely as a convenience to its customers and is intended only as a guide concerning the materials mentioned.
Any changes in the data sheet will be made without notification.
